Section 8.3 Recursion Revisited
One of the most common uses of numerical computing today is in the field of cryptography. Each time you check your bank account, sign on to a secure website to purchase something, or sign on to your computer, you are using cryptography. In a general sense, cryptography is concerned with encrypting and decrypting information that you do not want other people to see. In this section we will look at some functions that are used in everyday cryptographic programming. In practice there may be faster ways to implement these functions, but each of them has an interesting recursive implementation.
The algorithms in this section make use of Python’s modulo operator (%). Remember that
One of the earliest forms of cryptography used only simple modular arithmetic. Take the string shows you the function that produced the message. Look at the listing and see if you can figure it out.
"uryybjbeyq", for example. Can you guess what message is encrypted? Listing [lst_enc]1
#lst_encdef encrypt(m):
s = "abcdefghijklmnopqrstuvwxyz"
n = ""
for i in m:
j = (s.find(i) + 13) % 26
n = n + s[j]
return n
The
encrypt function illustrates a form of encryption known as the Caesar Cipher. It also goes by the name ROT13, which is a bit more descriptive. encrypt simply takes each letter in the message and adds 13 to its ordinal position in the alphabet. If the position goes past the end of the alphabet, it wraps around. This wraparound function is easily accomplished using the modulo operator. In addition, since there are 26 letters in the alphabet, this function is symmetric. The symmetry allows us to use the function to encrypt and decrypt the same message. If you pass the string "uryybjbeyg" to the encrypt function, it returns "helloworld".
Rotations by amounts other than 13 are possible; however, they are not symmetric with respect to encrypting and decrypting. Asymmetry would require us to write a separate decryption algorithm that subtracts the amount to rotate. In that case, we could generalize both the shows the decryption algorithm that takes the amount of rotation as a parameter. As an exercise you should be able to modify Listing [lst_enc] to accept a parameter that specifies a key.
encrypt and decrypt functions to take the amount of rotation as a parameter. In cryptographic terms, the rotation parameter is called the key and would be the number of positions to rotate. Given the message and the key, the encryption and decryption algorithms can do their jobs. Listing [lst_dec_key]2
#lst_dec_key3
#lst_encdef decrypt(m, k):
s = "abcdefghijklmnopqrstuvwxyz"
n = ""
for i in m:
j = (s.find(i) + 26 - k) % 26
n = n + s[j]
return n
Even if you keep the number
k from everyone except the person you are sending the message to, this simple form of encryption is not going to stop anyone from stealing your secrets for very long. In the remainder of this section, we will build up to a much more secure form of encryption, the RSA public key encryption algorithm.
Subsection 8.3.1 Modular Arithmetic Theorems
If two numbers,
Subsection 8.3.2 Modular Exponentiation
Suppose we wanted to know the last digit of
The answer to the second question is easy, given the third theorem from above.
-
Initialize result to 1.
-
Repeat
The above approach makes the computation simpler because we are keeping the result smaller rather than following it out to its full precision. However, we can do even better using a recursive approach.
x^n = \begin{cases} (x \cdot x)^{ n/2 } & \text{if :math:`n` is even} \\ (x \cdot x^{n-1}) = x \cdot (x \cdot x)^{\lfloor n/2 \rfloor} & \text{if :math:`n` is odd} \end{cases} \label{eqn:pow}Remember that for a floating point number
def modexp(x, n, p):
if n == 0:
return 1
t = (x * x) % p
tmp = modexp(t, n // 2, p)
if n % 2 != 0:
tmp = (tmp * x) % p
return tmp
Notice that in the above equation both the even and odd cases include a factor of
tmp. Also note that since we are computing modulo p we still apply the modulo operator at each step of the calculation. The solution in Listing [lst_pow]4
#lst_powSubsection 8.3.3 The Greatest Common Divisor and Multiplicative Inverses
A multiplicative inverse of a positive integer
The idea of multiplicative inverses in the world of modulo arithmetic may seem very confusing at first. How did we select 5 in the previous example? Is 5 the only multiplicative inverse of 3 modulo 7? Do all numbers
Let’s look at an example that may shed some light on the first question: how did we select 5 as the multiplicative inverse of 3 modulo 7? Look at the following Python session:
>>> for i in range(1, 40): ... if (3 * i) % 7 == 1: ... print i ... 5 12 19 26 33
This little experiment tells us that there are many multiplicative inverses (modulo 7) for
Do all pairs of numbers
The answer is that a number
Given two numbers
In terms of recursive algorithm design, Euclid’s algorithm is very straightforward. The base case is when
5
#lst_gcd1def gcd(a, b):
if b == 0:
return a
elif a < b:
return gcd(b, a)
return gcd(a - b, b)
Although Euclid’s algorithm is quite easy to understand and program, it is not as efficient as we would like, particularly if
6
#lst_gcd2def gcd(a, b):
if b == 0:
return a
return gcd(b, a % b)
Now that we have a way to know whether two numbers
We have reduced the problem of computing inverses to the problem of finding integers
7
#lst_gcd3def ext_gcd(x, y):
if y == 0:
return (x, 1, 0)
else:
(d, a, b) = ext_gcd(y, x % y)
return (d, b, a - (x // y) * b) |\label{line:gcd3_return}|
Notice that when we get the base case
\begin{aligned} d = & ay + b(x \mod{y}) \\ = & ay + b(x - \lfloor x / y \rfloor y) \\ = & bx + (a - \lfloor x / y \rfloor b)y\end{aligned}Note the substitution made in the second line,
8
#fig_gcd
Subsection 8.3.4 RSA Algorithm
Now we have all the tools we need to write the RSA encryption algorithm. The RSA algorithm is perhaps the easiest to understand of all the public key encryption algorithms. Public key cryptography was invented by Whitfield Diffie and Martin Hellman and independently by Ralph Merkle. The major contribution of public key cryptography was the idea that keys could come in pairs: an encryption key to convert the plaintext message to ciphertext, and a decryption key to convert the ciphertext back to plaintext. The keys only work one way so that a message encrypted with the private key can only be decrypted with the public key, and vice versa.
RSA gets its security from the difficulty of factoring large numbers. The public and private keys are derived from a pair of large (100–200 digit) prime numbers. Since long integers are native to Python, this is a fun and easy algorithm to implement.
n = p \times qgcd(e, (p - 1) \times (q-1)) = 1Finally, the decryption key
The numbers
\begin{aligned} c^d & = (m^e)^d \pmod{n} \\ & = m^{ed} \pmod{n} \\ & = m^1 \pmod{n} \\ & = m \pmod{n} \end{aligned}Before we turn all these equations into Python code, we need to talk about a couple of other details. First, how do we take a text message like “hello world” and turn it into a number? The easiest way is to simply use the ASCII values associated with each character and concatenate all the numbers together. However, since the decimal versions of the numbers of the ASCII values vary in the number of digits needed to represent them, we will use the hexadecimal numbers where we know very reliably that two hexadecimal digits represent a single byte or character.
| h | e | l | l | o | w | o | r | l | d | |
| 104 | 101 | 108 | 108 | 111 | 32 | 119 | 111 | 114 | 108 | 100 |
| 68 | 65 | 6c | 6c | 6f | 20 | 77 | 6f | 72 | 6c | 64 |
Putting all the hexadecimal digits together we could convert that large hex number into a decimal integer:
m = 126207244316550804821666916Python can handle this large number just fine. However, there are two reasons that real programs using RSA encryption break the message up into smaller chunks and encrypt each chunk. The first reason is performance. Even a relatively short email message, say 1k of text, will generate a number with 2,000 to 3,000 digits! If we raise that to a power of
The second reason for breaking the message into chunks is the restriction that
bit_length. Given the number of bits needed to represent a number, we can divide by eight to find the number of bytes. Since each character in the message can be represented by a single byte, this division tells us the number of bytes we can put in each chunk. Conveniently, this lets us simply break the message up into chunks of The characters “h,” “e,” and “l” have the hexadecimal values of
| :math:` m_1 = 6841708` | :math:` m_2 = 7106336` | :math:` m_3 = 7827314` | :math :m_4 = 27748 |
Note that breaking the message into chunks can be very tricky, in particular when the result of applying the RSA transformation to a chunk produces a number that is less than seven digits long. In this case we need to be careful to add a leading zero to the result when we glue our chunks back together again. You can see how this might happen in
Now let’s choose a value for
\begin{aligned} d & = ext\_gcd(45552780, 1471) \\ & = -11705609 \\ & = 45552780-11705609 \\ & = 33847171\end{aligned}Let’s use this information to encrypt the first chunk of our message:
c = 6841708^{1471} \pmod{45566533} = 16310024To check our work, let’s decrypt
m = 16310024^{33847171} \pmod{45566533} = 6841708The remaining chunks of the message can be encrypted using the same procedure and sent all together as the encrypted message.
Finally, let’s look at three Python functions.
def gen_keys(p, q):
n = p * q
m = (p - 1) * (q - 1)
e = int(random.random() * n)
while gcd(m, e) != 1:
e = int(random.random() * n)
d, a, b = ext_gcd(m, e)
if b < 0:
d = m + b
else:
d = b
return (e, d, n)
def encrypt(msg, e, n):
chunk_size = n.bit_length() // 8
all_chunks = str_to_chunks(msg, chunk_size)
return [
modexp(msg_chunk, e, n)
for msg_chunk in all_chunks
]
def decrypt(cipher_chunks, d, n):
chunk_size = n.bit_length() // 8
plain_chunks = [
modexp(cipher_chunk, d, n)
for cipher_chunk in cipher_chunks
]
return chunks_to_str(plain_chunks, chunk_size)
Here is a session that uses these functions to create public and private keys, encrypt, and decrypt as we did in the example above.
>>> msg = "Python" >>> e, d, n = gen_keys(5563, 8191) >>> print(e, d, n) 2646697 33043453 45566533 >>> c = encrypt(msg, e, n) >>> print(c) [22810070, 18852325, 34390906, 22805081] >>> m = decrypt(c, d, n) >>> print(m) Python >>>
The last thing to look at is the two helper functions that break our string into chunks and merge chunks into a string (Listing [lst_chunk]). These functions make use of Python
9
#lst_chunkbytearray objects, which allow us to store any string as a sequence of bytes. This makes it very convenient for us to convert a string to a sequence of hexadecimal digits and allows us to convert a sequence of hexadecimal digits back to a string.
def str_to_chunks(msg, chunk_size):
msg_bytes = bytes(msg, "utf-8")
hex_str = "".join([f"{b:02x}" for b in msg_bytes])
num_chunks = len(hex_str) // chunk_size
chunk_list = []
for i in range(
0, num_chunks * chunk_size + 1, chunk_size
):
chunk_list.append(hex_str[i : i + chunk_size])
chunk_list = [
eval("0x" + x) for x in chunk_list if x
]
return chunk_list
def chunks_to_str(chunk_list, chunk_size):
hex_list = []
for chunk in chunk_list:
hex_str = hex(chunk)[2:]
clen = len(hex_str)
hex_list.append(
"0" * ((chunk_size - clen) % 2) + hex_str
)
hstring = "".join(hex_list)
msg_array = bytearray.fromhex(hstring)
return msg_array.decode("utf-8")
In Listing [lst_chunk] we see the procedure for turning a string into a list of chunks. One important thing to note is that we must always make sure that our hexadecimal number corresponds to a character that is exactly two digits long. This means that sometimes we may need to add a leading zero. We can do this easily by using the string formatting expression
10
#lst_chunkf"{b:02x}". This expression creates a string that is exactly two characters long, with a leading zero at the beginning if necessary. Once we have created a single long hexadecimal string out of the entire message, we can then break up that long string into num_chunks chunks of hexadecimal numbers. This is what is happening in the for loop (starting on line 6). Finally, we can transform each hexadecimal number into an integer using the eval function and the list comprehension.
Transforming the decrypted chunks back to a string is as easy as creating a single long hex string and turning that hexadecimal string into a
bytearray. The bytearray has a built-in decode function to turn the bytearray into a string. The only tricky part of this procedure is that after the transformation process the number represented by the chunk may end up significantly smaller than the original. If this is the case we may need to add a leading zero to make sure that all of the chunks are the same length when we concatenate them back together again. The extra zeros are prepended to any chunk by using the string repetition operator in the expression "0" * ((chunk_size) - clen) % 2) where chunk_size represents the number of digits that should be present in the string and clen represents the actual number.
